LED Constant Voltage Brightness Controller, 24V, 4A/Ch, 3 Channels
€55,90
Skip to product information
LED Constant Voltage Brightness Controller, 24V, 4A/Ch, 3 Channels
€55,90
14-day right of withdrawal under EU consumer law
Shipped from our EU warehouses
Delivery across the Baltics, Finland and Sweden
LED Constant Voltage Brightness Controller, 24V, 4A/Ch, 3 Channels by Optonica — quality European LED lighting.
- IP20 rated
- Dimmable
- 2-year warranty
Technical specifications
| Product code | AC2-A3 |
| Dimmable | Yes |
| Input voltage, V | DC12-48 |
| Power grid frequency, Hz | Irrelevant |
| Power factor | Irrelevant |
| Energy consumption, kWh/1000h | 576 |
| Ingress protection | IP20 |
| Ambient temperature, °C | -30 / +55 |
| Product material | Plastic |
| Body color | White |
| Warranty, Year | 2 |
| Manufacturer | OptonicaLED |
| Brand | Optonica |
| Power, W | 3x(48-192) |
| Supply current, A | 12.5 |
| Output voltage, V | 3x(DC12-48) |
| Output current, A | 3x4 |
| Output type | Constant voltage |
| Output Connection Mode | Common anode (+) |
| Number of Channels | 3 |
| Dimming Control Type | PWM |
| Wireless Control | Yes |
| Wireless Control Type | RF 2.4GHz (WiFi) |
| LED strip type | Single color |
| Gross weight, g | 230 |
| Net weight, g | 173 |
| Supply current, from...to, A | >12…20 |
